Sinüzoid Açılımlı

Sinüzoid Açılımlı Petek Kirişler

Boyutlar:
Sinüzoid açılımlı petek kirişlerin boyutları değişkendir, ACB yazılımı ile optimize edilebilirler.

Kaynak, dizayna uygun olarak uygulanır.

Yüzey Durumu:
EN 10163-3: 2004 standartına göre sınıfı C, alt sınıfı 1.


IPE Profil Bazlı Petek Kiriş Ölçüleri
Profil Değerler
  y = (0,5 . a/2) . sin[π(x/b + 3/2)] + a/4
  G
kg/m		 Ht
mm		 a
mm		 b
mm		 w
mm		 AL
mm2/m
IPE A 20018,4316,0238,0429,52500,764
IPE 20022,4319,0238,0433,62500,768
IPE O 20025,1321,0238,0436,32500,779
IPE A 22022,2354,6275,2482,02500,843
IPE 22026,2357,6275,2486,12500,848
IPE O 22029,4359,6275,2488,82500,858
IPE A 24026,2387,4300,8526,62500,918
IPE 24030,7390,4300,8530,62500,922
IPE O 24034,3392,4300,8533,42500,932
IPE A 27030,7446,6359,2607,02501,037
IPE 27036,1449,6359,2611,12501,041
IPE O 27042,3453,6359,2616,52501,051

IPE A 30036,5505,6417,2687,22501,156
IPE 30042,2508,6417,2691,32501,160
IPE O 30049,3512,6417,2696,72501,174
IPE A 33043,0558,0462,0758,42501,250
IPE 33049,1561,0462,0762,52501,254
IPE O 33057,0565,0462,0768,02501,268
IPE A 36050,2616,2517,2837,62501,351
IPE 36057,1618,6517,2840,82501,353
IPE O 36066,0622,6517,2846,32501,367

IPE A 40057,4688,0582,0935,12501,464
IPE 40066,3691,0582,0939,22501,467
IPE O 40075,7695,0582,0944,72501,481
IPE A 45067,2785,8677,61068,12501,603
IPE 45077,6788,8677,61072,22501,605
IPE O 45092,4794,8677,61080,32501,622

IPE A 50079,4883,0772,01200,22501,741
IPE 50090,7886,0772,01204,32501,744
IPE O 500107,0892,0772,01212,42501,760
IPE A 55092,1974,6855,21324,72501,875
IPE 55090,7886,0772,01204,32501,744
IPE O 550123,0983,6855,21336,92501,893

IPE A 600108,01071,0948,01455,72502,013
IPE 600122,01074,0948,01459,82502,015
IPE O 600154,01084,0948,01473,42502,045

IPE 750 x 147147,01398,01290,01900,22502,510
IPE 750 x 173173,01406,81289,61912,22502,534
IPE 750 x 196196,01415,21290,41923,62502,552

HE Profil Bazlı Petek Kiriş Ölçüleri
Profil Değerler
  y = (0,5 . a/2) . sin[π(x/b + 3/2)] + a/4
  G
kg/m		 Ht
mm		 a
mm		 b
mm		 w
mm		 AL
mm2/m
HE 260 AA54,1381,0274,0517,92501,474
HE 260 A68,2387,0274,0526,02501,484
HE 260 B93,0397,0274,0539,62501,499
HE 260 M172,0427,0274,0580,42501,575
HE 280 AA61,2420,0312,0570,92501,593
HE 280 A76,4426,0312,0579,02501,603
HE 280 B103,0436,0312,0592,62501,618
HE 280 M189,0466,0312,0633,42501,694

HE 300 AA69,8451,0336,0613,02501,705
HE 300 A88,3458,0336,0622,52501,717
HE 300 B117,0468,0336,0636,12501,732
HE 300 M238,0508,0336,0690,52501,832
HE 320 AA74,2486,0370,0660,62501,740
HE 320 A97,6495,0370,0672,82501,756
HE 320 B127,0505,0370,0686,42501,771
HE 320 M245,0544,0370,0739,42501,866
HE 340 AA78,9523,0406,0710,92501,777
HE 340 A105,0533,0406,0724,52501,795
HE 340 B134,0543,0406,0738,12501,810
HE 340 M248,0580,0406,0788,32501,902
HE 360 AA83,7560,0442,0761,22501,814
HE 360 A112,0571,0442,0776,12501,834
HE 360 B142,0581,0442,0789,72501,849
HE 360 M250,0616,0442,0837,32501,934

HE 400 AA92,4636,0516,0864,52501,891
HE 400 A125,0648,0516,0880,82501,912
HE 400 B155,0658,0516,0894,42501,927
HE 400 M256,0690,0516,0937,92502,004
HE 450 AA99,7729,0608,0990,92501,984
HE 450 A140,0744,0608,01011,32502,011
HE 450 B171,0754,0608,01024,92502,026
HE 450 M263,0782,0608,01062,92502,096

HE 500 AA107,0822,0700,01117,32502,077
HE 500 A155,0840,0700,01141,72502,110
HE 500 B187,0850,0700,01155,32502,125
HE 500 M270,0874,0700,01188,02502,184
HE 550 AA120,0920,0796,01250,52502,175
HE 550 A166,0938,0796,01275,02502,209
HE 550 B199,0948,0796,01288,52502,224
HE 550 M278,0970,0796,01318,42502,280

HE 600 AA129,01017,0892,01382,32502,272
HE 600 A178,01036,0892,01408,22502,308
HE 600 B212,01046,0892,01421,72502,323
HE 600 M285,01066,0892,01448,92502,372
HE 600 x 337337,01078,0892,01465,22502,407
HE 600 x 399399,01094,0892,01487,02502,450
HE 650 AA138,01114,0988,01514,22502,369
HE 650 A190,01134,0988,01541,42502,407
HE 650 B225,01144,0988,01555,02502,422
HE 650 M293,01162,0988,01579,42502,468
HE 650 x 343343,01174,0988,01595,72502,500
HE 650 x 407407,01190,0988,01617,52502,543

HE 700 AA150,01212,01084,01647,42502,468
HE 700 A204,01232,01084,01674,62502,505
HE 700 B241,01242,01084,01688,22502,520
HE 700 M301,01258,01084,01709,92502,560
HE 700 x 352352,01270,01084,01726,22502,592
HE 700 x 418418,01286,01084,01748,02502,635

HE 800 AA172,01404,01268,01908,32502,660
HE 800 A224,01424,01268,01935,52502,698
HE 800 B262,01434,01268,01949,12502,713
HE 800 M317,01448,01268,01968,22502,746
HE 800 x 373373,01460,01268,01984,52502,782
HE 800 x 444444,01476,01268,02006,22502,824

HE 900 AA198,01600,01460,02174,82502,858
HE 900 A252,01620,01460,02201,92502,896
HE 900 B291,01630,01460,02215,52502,911
HE 900 M333,01640,01460,02229,12502,934
HE 900 x 391391,01652,01460,02245,42502,970
HE 900 x 466466,01668,01460,02267,22503,012

HE 1000 AA222,01798,01656,02443,92503,056
HE 1000 A272,01818,01656,02471,12503,095
HE 1000 B314,01828,01656,02484,72503,110
HE 1000 M349,01836,01656,02495,52503,130
HE 1000 x 393393,01844,21656,42506,72503,140
HE 1000 x 409393,01844,21656,42506,72503,140
HE 1000 x 488437,01854,01656,02520,02503,170
HE 1000 x 579494,01864,01656,02533,62503,190

HL Profil Bazlı Petek Kiriş Ölçüleri
Profil Değerler
  y = (0,5 . a/2) . sin[π(x/b + 3/2)] + a/4
  G
kg/m		 Ht
mm		 a
mm		 b
mm		 w
mm		 AL
mm2/m
HL 920 x 345345,01712,01570,02327,02503,450
HL 920 x 368368,01715,41568,82331,62503,460
HL 920 x 390390,01720,81569,62339,02503,480
HL 920 x 420420,01728,21570,42349,02503,500
HL 920 x 449449,01732,61569,22355,02503,510
HL 920 x 491491,01742,01570,02367,82503,520
HL 920 x 537537,01749,81569,62378,42503,540
HL 920 x 588588,01762,21572,42395,22503,570
HL 920 x 656656,01772,01570,02408,52503,600
HL 920 x 725725,01783,81569,62424,62503,630
HL 920 x 787787,01796,21570,42441,42503,660
HL 920 x 970970,01828,21570,42484,92503,740

HL 1000 AA296,01810,01656,02460,22503,479
HL 1000 A321,01818,01656,02471,12503,495
HL 1000 B371,01828,01656,02484,72503,510
HL 1000 M412,01836,01656,02495,52503,530
HL 1000 x 443443,01840,21656,42501,22503,530
HL 1000 x 483483,01848,01656,02511,82503,550
HL 1000 x 539539,01857,81655,62525,22503,580
HL 1000 x 554554,01860,01656,02528,22503,590
HL 1000 x 591591,01868,21656,42539,32503,600
HL 1000 x 642642,01876,01656,02549,92503,620
HL 1000 x 748748,01896,01656,02577,12503,670
HL 1000 x 883883,01920,01656,02609,72503,740

HL 1100 A343,02038,01896,02770,12503,710
HL 1100 B390,02048,01896,02783,72503,726
HL 1100 M433,02056,01896,02794,62503,746
HL 1100 R499,02066,01896,02808,22503,770
HL 1100 R499,02066,01896,02808,22503,770
